| Pipe Diametro | Number of Rolls Required / Size os the tape roll | ||
| 50 psi | 4Kg/cm | 10 layers | 150 psi | 11Kg/cm | 15 layers | 400 psi | 28Kg/cm | 20 layers | |
| 1/2" | 1 / T212 | 1 / T212 | 1 / T212 |
| 3/4" | 1 / T212 | 1 / T212 | 1 / T212 |
| 1" | 1 / T212 | 1 / T212 | 1 / T212 |
| 1.1/4" | 1 / T212 | 1 / T212 | 1 / T212 |
| 1.1/2" | 1 / T212 | 1 / T212 | 1 / T212 |
| 2" | 1 / T212 | 1 / T212 | 1 / T212 |
| 2.1/2" | 1 / T212 | 1 / T212 | 1 / T412 |
| 3" | 1 / T412 | 1 / T412 | 1 / T412 |
| 4" | 1 / T412 | 1 / T412 | 1 / T412 |
| Pipe Diametro | Number of Rolls Required / Size os the tape roll | ||
| 50 psi | 4Kg/cm | 10 layers | 150 psi | 11Kg/cm | 15 layers | 400 psi | 28Kg/cm | 20 layers | |
| 5" | 1 / T412 | 1 / T412 | 2 / T412 |
| 6" | 1 / T412 | 2 / T412 | 3 / T412 |
| 8" | 2 / T412 | 3 / T412 | 4 / T412 |
| 10" | 3 / T412 | 4 / T412 | 6 / T412 |
| 12" | 4 / T412 | 5 / T412 | 8 / T412 |
| 14" | 2 / T520 | 3 / T520 | 4 / T520 |
| 16" | 3 / T520 | 4 / T520 | 5 / T520 |
| 18" | 3 / T520 | 4 / T520 | 5 / T520 |
| >18" | Consult | ||
