Taurus TMAX is a high-performance epoxy compound formulated with 100% solids, ceramic fillers, and a flexible hybrid epoxy matrix, engineered to provide maximum resistance to abrasion and impact in the most demanding industrial applications. Solvent-free and highly resistant to acids and caustic solutions, TMAX is designed to protect metal surfaces exposed to extreme service conditions. Its smooth, non-sag consistency allows for easy application by trowel, putty knife, or by hand while wearing gloves, and can be applied in thicknesses of up to 500 mils (12.7 mm) in a single coat without sagging, even over minimally prepared surfaces and within tight maintenance schedules.
| Maximum Temperature (Depending on service) | Wet Service | Dry Service | 72°C | 95°C | 161°F | 203°F |
|---|---|---|---|
| Solids by Volume | 100% | ||
| Viscosity | Pasta | ||
| Mixed Density | 2.3 | ||
| Shore D Hardness | (ASTM D 2240) | 85 | |
| Pot Life | 25 min / kg at 72ºF | ||
| SAG Vertical Resistance at 21°C (70°F) and 12.7mm (500mils) | No sagging | ||
| Mix Ratio | 2:1 by Weight | Base: Activator | |
| Shelf life (unopened containers) | 3 years at 55-95ºF (13-35ºC) | ||
Surface Preparation
Proper surface preparation is critical to the long-term performance of this product. The exact requirements for surface preparation vary with the severity of the application, the expected useful life and the initial conditions of the substrate.
All sharp edges and welds shall be roughed to a radius of 3mm (120 thousand) with abrasive disc. The optimal preparation will provide a thoroughly cleaned surface of all contaminants and rough to an angular profile between 75-125 m (3-5 mil). This is normally achieved by initial cleaning and degreasing and then abrasive blasting to near-white metal cleaning, or by mechanical preparation.
Mixing
Mix the activator well in the base with the mixing rod scraping the sides and the bottom of the container.
Mix by weight 2 parts Base to 1 part of Activator. Mix thoroughly to produce a uniform and without stripes. Never put solvents.
Application
Use a heavy plastic brush or putty knife to apply a minimum thickness of 6 mm. Work the material in the substrate profile to achieve maximum adhesive and remove any trapped air. Contour to correct the shape with putty knife material or plastic applicator. If mold is used or shape, be sure to coat its surface with an agent of release to prevent adhesion of the material.
Application Temperature:
Keep between 55 and 95°F (17 to 35°C). Substrate: keep between 45 and 105°F (7 to 40°C). The temperature difference of the substrate and material should never exceed 10°F (5°C). The substrate shall be at least 5°F (3°C) above the dew point. Do not apply if the relative humidity exceeds 90%. If necessary, heat the metal before surface preparation using electric heater or heat lamp. Never use gas, oil or kerosene heaters, as they will leave a greasy residue on the
metal surface. For best results, keep all material in the warm zone overnight (75°F+) for easy mixing.
Cured Time:
| 16°C (60°F) | 25°C (77°F) | 32°C (90°F) | |
|---|---|---|---|
| Tack Free | 4 hours | 2 hours | 1 hour |
| Light Load | 12 hours | 6 hours | 3 hours |
| Term Overlay | 16 hours | 10 hours | 5 hours |
| Full Charge | 24 hours | 12 hours | 6 hours |
| Complete Chemical | 48 hours | 24 hours | 12 hours |
Clean: Tools should be thoroughly cleaned immediately after use with a strong alkaline detergent.
Safety: Before using any product, review the Safety Data Sheet (SDS) or Safety Data Sheet for your area. Follow standard confined space
entry and work procedures, if applicable.
